“SF” Volumetric Screw Feeders 2017-01-28T16:46:52+00:00

“SF” Volumetric Screw Feeders – Details

Volumetric Screw Feeders are used to control the flow rate of bulk material from a bin or hopper. They are designed to be flood fed, so that regardless of the amount of material in a hopper above the inlet, the outlet rate will remain consistent. Screw feeders are available to feed a wide range of materials.

Essmueller screw feeders are available in standard trough lengths, and in sizes to suit almost any need. They are available in single, double, triple and live bottom configurations. Multiple screws are used to control the flow rate of bulk material that tends to bridge a bin or hopper. Live bottom screw feeders are designed to be mounted under bins to control the flow rate of material that tend to pack or bridge. Tapered pitch or variable pitch screws are used in screw feeders to draw the bulk material evenly from all areas of inlet opening. CEMA standard components are selected based on the material to be handled.

“SF” Volumetric Screw Feeders – Options

> Heavy Duty Flighting
> Heavy duty components
> Short pitch flighting
> Double flighting
> Variable pitch flighting
> Tapered flighting
> Stainless steel or galvanized

> Special materials
> Flow indication switch
> Plug switch
> Abrasion resistant liners
> Tubular trough
> Special shaft seals
> Feeder extensions

> Direct inlet
> Non-flared
> Flared inlet single-side
> Flared inlet double side
> Flared inlet extensions
> Open end discharges
> Electric motor and drive packages

CAPACITIES OF SINGLE SCREW FEEDERS
MAXIMUMCFH @CFH @CONSULT ESSMUELLER FOR YOUR SPECIFIC APPLICATION
SIZERPM1 RPMMAX. RPM
4751.46110THESE CAPACITIES ARE BASED ON 100% OF THEORETICAL CAPACITY
6704.98349WITH STANDARD PITCH AND SCREW PIP WITH CHOKE LOADED FREE
96518.51203FLOWING MATERIALS
126044.42664
1455703850CAPACITIES, SPEEDS AND HORSEPOWERS REQUIRED WILL VARY
1650104.75235BY MATERIAL, MOISTURE CONTENT, NON-STANDARD PITCH OR PIPE
18451516795SIZE
20402098360
243036310890

"SF" SCREW FEEDER DIMENSIONS
SIZEAB*CDEFGHJKL
45303 5 / 83 3 / 454 5 / 82 1 / 26 1 / 8107 1 / 23
67364 1 / 2575 5 / 83 1 / 281410 1 / 23
910426 1 / 87 1 / 897 7 / 8511 1 / 818143
1213487 3 / 48 7 / 8109 5 / 86 1 / 214 1 / 42217 1 / 23
1415549 1 / 410 1 / 81110 7 / 87 1 / 216 3 / 42419 1 / 23
16175610 5 / 811 1 / 811 1 / 2128 1 / 219 1 / 82822 1 / 23
18195812 1 / 812 3 / 812 1 / 813 3 / 89 1 / 221 5 / 831253
20216013 1 / 213 3 / 813 1 / 21510 1 / 2243427 1 / 23
24256416 1 / 215 3 / 816 1 / 218 1 / 812 1 / 2294032 1 / 23
